Product Description
- Weight capacity: 450lbs
- Unique suspension system and high-density foam seat provide a smooth and comfortable ride
- The sophisticated controller coupled with 14" aluminum cast drive wheels offer excellent maneuverability
- Comfortable 22" (20" with seat elevator) wide captain seat has swivel and folding capabilities with adjustable head and backrest
- Aluminum footplate with flip-up height and angle adjustability provides various comfort positions
- Programmable controller with a wide range of selections to suit the needs and demands of different users
- Non-programmable controller also available
- Colors available: Red, Blue
- Options: swing-away joystick, elevating leg rests, oxygen tank holder, power seat lift, cane & crutch holder, rear foldable basket, walker holder, canopy
Specifications
| Max Speed | 5mph |
| Range | up to 20 miles |
| Turning Radius | 21" |
| Ground Clearance | 4" |
| Motor | DC 24V, 240W |
| Controller | Dynamic Shark 60A/PG VR2 60A |
| Battery | 12V/22NF(50AH) x 2pcs |
| Charger | 5A off-board |
| Gradient | 10° |
| Casters | 9" foam-filled tires |
| Drive Wheels | 14" foam-filled tires |
| Brakes | intelligent, regenerative, electromagnetic |
Dimensions
| Gemini with Seat Lift | Gemini | |
| Seat Width | 20" | 22" |
| Seat Depth | 20" | 22" |
| Seat Height | 24"-29" | 22"-24" |
| Armrest Height | ||
| Backrest Height | 20" | 22" |
| Min. Footrest Extension | ||
| Max. Footrest Extension | ||
| Overall Length | 41" | 41" |
| Overall Height | 45" | 45" |
| Overall Width | 24" | 24" |
| Folded Width | ||
| Total Weight | 350 lbs | 242 lbs |
| Capacity | 350 lbs | 450 lbs |
Product Literature
Service Manual
Owner Manual
